FARASENS – TECHNOLOGY

Provide comprehensive solutions for industrial automation and instrumentation in place of all industries

high-quality range of transducers, sensors, cabling, electronics, software and associated hardware gives you total solutions for monitoring and protecting your critical machines and processes. Our Vibro-Meter® products include vibration sensors, dynamic pressure sensors, proximity sensors, air-gap sensors, expansion probes, ice-detection sensors, VM600 rack based systems, VibroSmart® and VibroSight® systems and more.

Control Techniques are 100% focused on delivering world-class motor control variable speed drives and power conversion technologies that are used in industry, commerce and renewable energy schemes. Our drive solutions help businesses to significantly reduce energy costs and improve their operating efficiency.

industrial pc, motherboards, touch screen monitors and tablets, network and IOT solutions

These include electric power and control systems, electric motors and generators, LV and MV drives and precise Power Supply and Power Quality components.

Remote access and industrial equipment management

all solutions for distance and position precise measuring with different kind of sensors, digital gauges, digital scales, potentiometers and encoders.

Little

About Us

We Are Industrial Automation Division of FARATEC Company. Fanavaran Rahbordi Ati Company with the registered trademark, FARATEC acts as an engineering and knowledge-based company with the goal of improving the quality of engineering services and supplying technology and requirements of the industry. The company, while providing a wide range of industrial equipment and spare parts in different industries, can provide all engineering services such as Design, Construction, erection, Commissioning, maintenance and training to its customers as well. FARATEC Company qualified as a 5th grade contractor in the oil and gas industry sector as well as in the field of industry and mining from the planning and budget organization and is proud to receive ISO 9001: 2015, ISO14001: 2015, ISO18001: 2007, ISO / TS 29001: 2010 certificates from Germany’s DQS Certification Company.

Green pushbutton (PG)

Mushroom button
pull-to-release (E6)

Red LED Indicator (LR)

Blue Pushbutton
Actuator (IB)

QUINTEX CB-P7/10369

• Material : Polyester, glass fibre reinforced (GRP)
• Dimension (mm) : 122 x 122 x 90 (1-and 2-modules)
220 x 120 x 90 (3 modules)
online calculation up to 12 modules (see button)
• Zones : 1, 21, 2, 22
• Group : IIC
• Ingress protection : IP 65
• Ambient temperature : -55°C up to + 60°C
• Temperature class : T6 /T4
• Terminals : 0,5 - 2,5mm²
• Switching modules : up to 250V / 16A
• Signal modules : 24 -240 V AC; 24 - 36 V DC

Easy rope fixation
with rope clip

Measuring Rope
(Stainless Steel)

Dynamic Spring Drive
with PA6 case for high
displacement speed

Waterproof Housing
IP65 or IP67

Draw Wire Sensors SX-Series

Ball bearing drill
Protection

Bushing

Anodised Aluminium
Housing

High Linearity

2 Ball Bearings

•Ranges : from 50 to 5000 mm
•Linearity max. : ±0.2 %
•Output analog : 0...10 V, 4...20 mA, Potentiometer
•Output digital : TTL, HTL, SSI, Profibus, CANopen,
EtherCAT, Profinet
•Protection class : IP65 (optional IP67K)

Dual Link resolutions,
Real Time Control

Output lead from the
power adapter

Waterproof Housing
IP65 or IP67

EDID management

USB port

Audio port

ADDERLINK X-DVI PRO-DL

• DVI-D Interface - digital only :
The system supports resolutions to a
maximum of 2560x1600 @60Hz.
• Computer connections Transmitter (TX) :
DVI-D, Audio 3.5mm in, USB type B.
• Computer connections Receiver (RX) :
DVI-D, Audio 3.5mm out, USB type A x 4
• Physical design :
Compact case, robust metal construction
120mm/4.7” (w) x 75mm/3” (d) x
26mm/1” (h) 320g/0.7lb.
• Approvals :
CE, FCC.

50 meters over a single
CATx cable

EDID management

Audio port

CONTROL TECHNIQUES POWERDRIVE F300 AC DRIVE

Dual Link resolutions,
Real Time Control

Output lead from the
power adapter

• Intelligence: Onboard PLC
Onboard comms: RS485
• Safety :
1 x Safe Torque Off (STO) terminal
SIL3/PLe compliant
• Keypad :
Hand-Off-Auto control keypad as standard
• Option slots :
3
• Parameter cloning via :
PC tools
Smartcard
SD card

HDD active LED

Power switch

FANLESS EMBEDDED BOX PC SERIES AEC-6638

Line Out

Power LED

Antenna Hole x 2

USB 2.0 x 2

• 4th Generation Intel® Core™ i7/i5/i3 Processor
CPU :
i7-4700EQ (2.4 GHz)[37W]/
i5-4400E (2.7 GHz)[37W]/
i3-4100E (2.4 GHz)[37W]
• COM Port x 3, USB 3.0 x 2 , USB 2.0 x 2
• Intel® Gigabit Ethernet x 2 (Intel® I217/I218 Gigabit PHY
& Intel® I210/I211 Gigabit)
• VGA Output Resolution: Up to 2048 x 1536 (QXGA) @ 60 Hz
• DVI-D Output Resolution: 1920 x 1200 @ 60 Hz
• HDMI Output Resolution: Up to 3840 x 2160 @ 30 Hz
Mini-Card x 1 or mSATA x 1 Selected by Jumper Setting
• Fanless System Design
• AAEON's Hi-Safe & Hi-Manager Support

SD MemoryCard Slot

Start/Stop Key

Stylus

LCD screen

PAPERLESS RECORDER TOUCH SCREEN GX10

USB Port

Front panel door
lock mechanism

Start/Stop Key

Operation Panel

Menu Key

• DC voltage, standardized signal, thermocouple, RTD, DI,
DC current (with external shunt resistor), DC current, resistance
• DCV : 20 mV, 60 mV, 200 mV, 1 V, 2 V, 6 V, 20 V, 50 V, 100 V
• Standard signal : 0.4-2 V, 1-5 V
• Resistance : 20, 200, 2000 Ω
• Thermocouple : R, S, B, K, E, J, T, N, W, L, U,
W97Re3-W75Re25, KpvsAu7Fe, Platinel 2, PR20-40,
NiNiMo, W/WRe26, N(AWG14), XK GOST
• RTD : Pt100, JPt100, Cu10 GE, Cu10 L&N,
Cu10 WEED, Cu10 BAILEY, Cu10 (20°C) α=0.00392,
Cu10 (20°C) α=0.00393, Cu25 (0°C) α=0.00425,
Cu53 (0°C) α=0.00426035, Cu100 (0°C) α=0.00425,
J263B, Ni100 (SAMA), Ni100 (DIN), Ni120, Pt25, Pt50,
Pt200 WEED, Cu10 GOST, Cu50 GOST, Cu100 GOST,
Pt46 GOST, Pt100 GOST, PT500, PT1000
• DI : Level, Contact
• DC current : 0-20 mA, 4-20 mA

Rugged Aluminium
Housing

USB Type B
configuration port

Plastic ends

LCD screen

ANYBUS X-GATEWAY MODBUS RTU SLAVE

Network Connector 1

LED indicators

Network Connector 2

Plastic ends

LED indicators

• Power supply: 24 VDC +/- 20% via 2-pole 5.08 mm
Phoenix pluggable screw connector
• Current consumption: max. 400mA (Typical 200mA)
• Enclosure material: Aluminium and plastic
• Installation position: Vertical / Flat*
•Galvanic isolation: YES, on both BUS/Ethernet side
• Mechanical rating: IP20, NEMA rating 1
• Mounting: DIN-rail (EN 50022 standard)
• I/O configuration: via USB port with Anybus
Configuration Manager software
• Certifications: CE, CULUS, RoHS

MPC4 & AMC8 modules
Machinery protection

MPC4 module
Protection of vibration
& dynamic channels

ABE04x rack
19’’ standardx Backplane,
no internal wiring

IRC4 module
Process complex
Boolean equations

VM600 Meggitt

MPC4 & AMC8 modules
Machinery protection

AMC8 module
Protection of temperature
& plant process channels

CPU-M module
Network communications

CMC16 module
Condition monitoring

RPS6U module
Redundant power supply

IRC4 module
Process complex
Boolean equations

• For continuous on-line protection and condition
monitoring of heavy-duty critical rotating machinery
• 19’’, 6U standard rack
• Flexible, expandable
• All MPS and CMS functions
